Dayton Audio RST28A-4 1-1/8" Reference Series Aluminum Dome Tweeter 4 Ohm

The Dayton Audio RST28A-4 1-1/8" aluminum dome Reference Series tweeter has remarkable clarity, low free air resonance, exceptional efficiency, and smooth frequency response, a combination seldom found in the industry at any price. This upgrade over the original RS28A-4 provides incredible performance at an amazing value.

Key Features

  • 1-1/8" aluminum diaphragm offers remarkable clarity without the typical harshness of metal domes
  • Exceptional efficiency at 92.5 ±3 dB from 1.5 kHz to 19 kHz and a smooth frequency response
  • Well-designed phase bridge to balance the response in the upper octave
  • Tuned rear chamber and high-quality Ferrofluid for excellent low-end response
  • Low-distortion motor system achieves a rare level of transparency
  • Matches the performance of even the most expensive audiophile high-frequency transducers



The Dayton Audio RST28A-4 aluminum dome Reference Series tweeter offers exceptional efficiency from 1,500 Hz to 20,000 Hz with smooth and well controlled frequency response. This tweeter's unique black anodized 1-1/8" aluminum diaphragm and state-of-the-art motor system not only match the look and features of Dayton Audio's Reference Series woofers and midranges, but also the clean, detailed, and uncolored sound you have come to expect. A specialized damped rear chamber, well-designed phase bridge, rigid mesh grill, and several distortion-reducing paths in the motor are just a few of the features that allow these tweeters to outperform some the most expensive audiophile high-frequency transducers.

For applications like line arrays or compact mini-monitors that demand a smaller faceplate, an optional truncated faceplate is available.
For the replacement diaphragm, see part number 275-133

Properties
Artikel-Nr.: 275-131
Außenmaß: 104,7mm
DC Resistance (Re): 3 Ohm
EAN: 848791004896
Einbautiefe: 44,5 mm
Einheit: Stück
Elektrische Güte (Qes): 165
Frequenzbereich: 1,500 bis 20,000Hz
Gesamtgüte (Qts): 93
Hochtöner Typ: Metall Kalotte
Impedanz (Z): 4 Ohm
Marke: Dayton Audio
Mechanische Güte (Qms): 215
Modell: RST28A-4
Nennbelastbarkeit: 80 Watt
Resonanzfrequenz (fs): 775Hz
Schwingspulenind. (Le): 0,03mH
Sensitivität: 92,5dB 2,83V/1m
Data according to manufacturer. Errors and changes reserved.
Manufacturer "Dayton Audio"
