Ultimax15CB Kit/Bausatz

Ultimax15CB Kit/Set

Ultimax 15 CB Kit passive

Dayton Audio 15" Ultimax Subwoofer without Enclosure Bundle

Assembly:

Dayton Audio UM15-22

Properties:

Dayton Audio UM15-22 15" Subwoofer for e.g. 92 Liter Enclosure - Flat Pack

About the Case
This sturdy enclosure was specifically designed for the Dayton Audio 15" Ultimax subwoofer.

During the CNC manufacturing process, grooves and joints are cut into the back panel to join the plates
precisely aligned. A unique two-part strut provides superior stiffness without the
Performance of the subwoofer. Both side walls feature 19mm rabbeted extensions
with cutouts to perfectly mount the first piece of the two-part, double-thick baffle.

The final result is a resonance-free, closed subwoofer enclosure, specifically designed to
the best performance from the 15" Ultimax subwoofer by Dayton Audio. All that's left to do
remains, is to refine it to match your decor or paint it to stand out. If your
Friends ask afterwards, you have the pleasure to say: "I built it myself!"

Spezifications: - Plate thickness: 22mm, the front baffle is 38mm - Plate material: Medium density
Fiberboard (MDF) - Finished Net Cabinet Volume (excluding the double thick baffle, the
Bracing and the low-frequency volume): 92L - External dimensions: 490" H x 490" W x 510mm D

Lassen Sie sich überzeugen und besuchen Sie uns gerne vor Ort, um in unserem Hörraum in eine Welt der
Dive into tones.

Technical Specifications:

Frequenzumfang:       f-3dB: Active (recommended) 20-120Hz / Passive Fc 36Hz, Qtc 0.7

SPL:                            88.5dB

B/H/T:                        490x490x510mm

Total impedance:      2+2 Ohms (in series 4 Ohms)

Funtion principle:       92 liters closed

Scope of delivery:

• Screws
• Chassis
• Terminal
• LS Cable
• Blueprint

Die Lieferzeit bezieht sich auf den Bausatz ohne Gehäuse.

Bei der ausgwewählten Anzahl handelt es sich um Stück,nota couple.
