T.A.C. T-22 Röhrenvollverstärker Silver
Skip image gallery
Picture similar to product
Product number:
206453
Manufacturer:
Sintron
Weight:
19 kg
Min. order quantity:
1
T.A.C. T-22 Tube Integrated Amplifier Silver
Product Information
Proven technology in modern design, this is how the T-22 from T.A.C. presents itself. The two EL34
Tubes per channel operate in push-pull mode. A feedback tap on the output transformer minimizes the
Distortions and represents an ultra-linear circuit. All used sound-defining components are
before installation. To emphasize the puristic character, a sound control was omitted.
waived.
Technical Specifications
|
Type: |
T-22 Tube Amplifier |
|
Frequency range: |
20 Hz - 60 kHz (+/- 3 dB) |
|
Performance: |
2 x 40 Watt (4-8 Ohm) |
|
Distortion factor: |
< 1% (1 kHz |
|
Signal-to-noise ratio: |
> 90 dB |
|
Input impedance: |
100 kOhm |
|
Entries: |
4 x Stereo RCA |
|
Outputs: |
1 x Stereo RCA Line Out |
|
Tubes: |
4 x EL34 |
|
Measurements: |
330 x 175 x 400 mm |
|
Weight: |
19 kg |
