EX-40/8
Skip image gallery
Picture similar to product
Product number:
16341
Manufacturer:
Monacor
Weight:
0.4 kg
Min. order quantity:
1
EX-40/8
Audio exciters/resonators, 20 W, 4 Ω (/4) or 8 Ω (/8)
Exciters are suitable for music and speech reproduction over vibratable surfaces. They are simply glued onto doors, cabinet doors, shelves, tabletops, lightweight walls, ceiling panels, or a variety of other surfaces to be set into vibration and create an impressive sound with these surfaces throughout the entire environment.
- In dependence on the mounting surface, very broadband reproduction with astonishing richness of sound
- High sound quality
- High Resilience
- Suitable for discreet sound, e.g. on doors, cabinets, shelves, glass panes
- Delivery with 3M adhesive pad
Technical Specifications
EX-40/8
| Low ohm | 1 |
| Impedance (Z) | 8 Ω |
| Frequency range | fx-20000 Hz |
| Resonance Frequency (fs) | 300 Hz |
| Rated Power (RMS) | 20 W |
| Music Load Capacity (MAX) | 40 W |
| Max. Nominal Sound Pressure | no information |
| Voice coil diameter. | Ø 32 mm |
| Voice coil former | KSV |
| Dimensions | Ø 61 mm x 20 mm |
| Outer diameter | Ø 61 mm |
| Width | 61 mm |
| Height | 61 mm |
| Depth | 20 mm |
| Color | Black/Silver |
| Permissible Operating Temperature | 0-40 °C |
| Weight | 0.129 kg |
| Packaging unit | 1 |
| Packaging dimensions (W x H x L) | 0.08 x 0.033 x 0.08 m |
| Gross weight | 0.144 kg |
| Net weight | 0.129 kg |
