Dayton Audio RSS265HO-4
Dayton Audio RSS265HO-4 10” Reference HO Subwoofer 4 Ohm
Built for extreme performance in the smallest 10" subwoofer speaker enclosures, the Dayton Audio Reference Series RSS265HO-4 features an anodized aluminum cone, 4-layer voice coil, and optimized distortion-reducing magnet system.
Key Features
- Extensively vented motor eliminates compression and allows quiet excursion
- Extra-thick black anodized aluminum cone for maximum rigidity
- Triple shorting ring motor for ultra-low distortion
- 4-layer coil for high power handling
- Optimized parameters for small enclosures
- Highest quality materials throughout for long-lasting performance
Dayton Audio RSS265HO-4 10" Reference HO Subwoofer 4 Ohm
As with the rest of the Reference Series, the main focus of the Dayton Audio RSS265HO-4 10" subwoofer is ultra-low-distortion. Second, third, and intermodulation distortion are kept extremely low by utilizing three short-circuit paths within the motor structure. A durable aramid fiber spider and extensive venting throughout provide quiet and uniform excursion. The black anodized cone, rubber surround, and custom basket give this 10" driver a unique, high-end look. Choose the high output version for automotive applications or for equalized high-power home subwoofer speaker systems.
| Artikel-Nr.: | 295-462 |
|---|---|
| Außenmaß: | 264,16mm |
| Bohrlochanzahl: | 6 |
| DC Resistance (Re): | 3,5 Ohm |
| EAN: | 844632006920 |
| Eff. Membranfläche (Sd): | 349,7cm² |
| Effektive Bewegte Masse (Mms): | 201g |
| Einbautiefe: | 136,4 mm |
| Einbauöffnung: | 235 mm |
| Einheit: | Stück |
| Elektrische Güte (Qes): | 0,39 |
| Frequenzbereich: | 24 bis 600Hz |
| Gesamtgüte (Qts): | 0,35 |
| Größe: | 10 " |
| Impedanz (Z): | 4 Ohm |
| Korbmaterial: | Aluminium Guss |
| Kraftfaktor (BL): | 17,6T·m |
| Lineare Auslenkung (Xmax): | 12,3mm |
| Magnet: | Ferrit |
| Marke: | Dayton Audio |
| Mechanische Güte (Qms): | 4,02 |
| Membranmaterial: | Aluminium |
| Modell: | RSS265HO-4 |
| Nachgiebigkeit (Cms): | 0,17mm/N |
| Nennbelastbarkeit: | 600 Watt |
| Resonanzfrequenz (fs): | 26,9Hz |
| Schwingspulendurchmesser: | 64 mm |
| Schwingspulenind. (Le): | 1,74mH |
| Schwingspulenkörper: | Aluminium |
| Schwingspulenmaterial: | Kupfer |
| Sensitivität: | 87,2dB 2,83V/1m |
| Sickenmaterial: | Gummi |
| Äquivalentvolumen (Vas): | 29,449 l |
