Dayton Audio RSS210HF-4

Dayton Audio RSS210HF-4 8” Reference HF Subwoofer 4 Ohm

The Dayton Audio Reference Series subwoofers take the quality and performance of the much acclaimed RS line into the subwoofer realm. The black anodized cone, rubber surround, and custom basket give this driver a unique, high-end look.

Key Features

  • Extensively vented motor eliminates compression and allows quiet excursion
  • Lightweight black anodized aluminum cone for rigidity and lower moving mass
  • Suitable for sealed or vented enclosures
  • Triple shorting ring motor for ultra-low distortion
  • 2-layer coil for reduced back EMF
  • Highest quality materials throughout for long-lasting performance

Dayton Audio RSS210HF-4 8" Reference HF Subwoofer 4 Ohm


The Dayton Audio Reference Series subwoofers take the quality and performance of the much acclaimed RS line into the subwoofer realm. As with the rest of the Reference Series, the main focus of these subwoofers is ultra-low-distortion. Second, third, and intemodulation distortion are kept extremely low by utilizing three short-circuit paths within the motor structure. A durable aramid fiber spider and extensive venting throughout provide quiet and uniform excursion. The black anodized cone, rubber surround, and custom basket give this driver a unique, high-end look. Choose the high fidelity version for home systems when you are looking for clean, low bass and are not restricted by cabinet size.

Properties
Artikel-Nr.: 295-456
Außenmaß: 213,10mm
Bohrlochanzahl: 6
DC Resistance (Re): 3,1 Ohm
EAN: 844632062308
Eff. Membranfläche (Sd): 219cm²
Effektive Bewegte Masse (Mms): 78,4g
Einbautiefe: 124 mm
Einbauöffnung: 184,9 mm
Einheit: Stück
Elektrische Güte (Qes): 0,69
Frequenzbereich: 27 bis 1,000Hz
Gesamtgüte (Qts): 0,57
Größe: 8 "
Impedanz (Z): 4 Ohm
Korbmaterial: Stahl
Kraftfaktor (BL): 8,12T·m
Lineare Auslenkung (Xmax): 9mm
Magnet: Ferrit
Marke: Dayton Audio
Mechanische Güte (Qms): 3,25
Membranmaterial: Aluminium
Modell: RSS210HF-4
Nachgiebigkeit (Cms): 0,37mm/N
Nennbelastbarkeit: 280 Watt
Resonanzfrequenz (fs): 29,6Hz
Schwingspulendurchmesser: 50,8 mm
Schwingspulenind. (Le): 0,7mH
Schwingspulenkörper: Aluminium
Schwingspulenmaterial: Kupfer
Sensitivität: 85,6dB 2,83V/1m
Sickenmaterial: Gummi
Äquivalentvolumen (Vas): 23,786 l
Data according to manufacturer. Errors and changes reserved.
