Dayton Audio LW150-4
Dayton Audio LW150-4 6" Low Profile Woofer 4 Ohms
The Dayton Audio LW150-4 6" woofer's unique venting allows zero-clearance installation in ultra-low profile applications. Solid bass output can be produced from spaces never thought possible.
Key Features
- Very low profile woofer fits in tight spots
- Flat woven glass-fiber/honeycomb aluminum composite cone
- Dual sandwiched spiders and S-shaped surround enhance linear travel capability
- Large 1-1/4" 4-layer voice coil and optimized T-pole gap geometry
- Peripheral holes in spider landing enable zero-clearance venting in shallow enclosures
- Great for on-wall, in-wall, or car audio applications
Dayton Audio LW150-4 6" Low Profile Woofer 4 Ohms
The unique and versatile Dayton Audio LW150-4 6" woofer was designed for space limited, minimum depth applications. Its low-profile frame and unique venting permit the back of the woofer to be placed directly against cabinet walls or even embedded (countersunk) into the cabinet, resulting in an enclosure less than 1-1/2" deep. Great match for today's ultra-thin TVs or use as a down firing subwoofer in a low powered system, low-frequency down-firing driver in a center channel/monitor stand, or bookshelf stand.
| Artikel-Nr.: | 295-255 |
|---|---|
| Außenmaß: | 152,4mm |
| Bohrlochanzahl: | 4 |
| DC Resistance (Re): | 3,6 Ohm |
| EAN: | 848791001864 |
| Eff. Membranfläche (Sd): | 91cm² |
| Effektive Bewegte Masse (Mms): | 218 |
| Einbautiefe: | 38,1 mm |
| Einbauöffnung: | 130,2 mm |
| Einheit: | Stück |
| Elektrische Güte (Qes): | 72 |
| Frequenzbereich: | 60 bis 1,800Hz |
| Gesamtgüte (Qts): | 64 |
| Größe: | 6 " |
| Impedanz (Z): | 4 Ohm |
| Korbmaterial: | Aluminium Guss |
| Kraftfaktor (BL): | 6,51T·m |
| Lineare Auslenkung (Xmax): | 4mm |
| Magnet: | Neodym |
| Marke: | Dayton Audio |
| Mechanische Güte (Qms): | 601 |
| Membranmaterial: | Kohlefaser Composite |
| Modell: | LW150-4 |
| Nachgiebigkeit (Cms): | 0,296mm/N |
| Nennbelastbarkeit: | 40 Watt |
| Resonanzfrequenz (fs): | 62,6Hz |
| Schwingspulendurchmesser: | 31,8 mm |
| Schwingspulenind. (Le): | 0,86mH |
| Schwingspulenkörper: | Kapton / Polyimide |
| Schwingspulenmaterial: | Kupfer |
| Sensitivität: | 86,1dB 2,83V/1m |
| Sickenmaterial: | Gummi |
| Äquivalentvolumen (Vas): | 3,398 l |
