Gehäuse AMPTlich 12 250
Gehäuse AMPTlich 12 250
AMPtlich RSS315 Kit
Dayton Audio RSS315 Subwoofer Enclosure Kit
Properties:
60L Flat Pack Enclosure Kit for Dayton Audio RSS 12" Subwoofer
About the Case
This enclosure was specifically designed for the Dayton Audio 12" RSS subwoofer.
During the CNC manufacturing process, rebates and joints are cut into the back panel to precisely align the boards. A unique two-part brace provides superior rigidity without compromising the subwoofer's performance. Both side panels feature rebated extensions with cutouts to perfectly mount the first piece of the two-part, double-thick baffle.
The final result is a resonance-free, sealed subwoofer enclosure, specifically designed to get the best performance out of the 12" RSS315HFA-8 subwoofer from Dayton Audio. All that remains to be done is to finish it to match your decor or paint it to stand out.
Spezifikationen:- Panel thickness: 19mm, baffle 38mm - Panel material: Medium Density Fiberboard (MDF) - Finished net cabinet volume (minus double thick baffle, bracing, and woofer volume): 60L - External dimensions: 430mm H x 430mm W x 430mm D - Weight: 17kg
Attention please note and for change requests please in the comment field or by email change requests
address:
In all our enclosure kits, unless otherwise mentioned, terminal cutouts for our terminal
T105 on the back of the case, prefabricated!
All housing kits (not glued or painted) are without rounded edges or chamfers!
Chamfers or rounds are only made on fully assembled housings.
Über the subwoofer
The subwoofers of the Dayton Audio Reference Series continue the quality and performance of the highly praised RS line into the realm of subwoofers. As with the other models of the Reference Series, the main focus of the 12" driver RSS315HFA-8 is on extremely low distortion. Secondary, tertiary, and intermodulation distortions are kept extremely low by the use of three magnetic shorting paths within the motor structure. A durable aramid fiber spider and extensive ventilation openings ensure quiet and smooth excursion. The black anodized cone, rubber surround, and custom-made basket give this driver a unique high-end look. Choose this High Fidelity (HF) version for home speaker systems if you value clean, deep bass and are not restricted by enclosure size.
To the YT video from "Frank's Workshop of Speaker Technology" about our 12" RSS315 Subwoofer
Whoever is not yet familiar with the YouTube channel should urgently get acquainted with it. There you will find content about the special kind of Hi-Fi.
Frank himself says about the channel: "Here you will find the collected knowledge about speaker development, both for beginners and up to well-founded know-how, from the professional.
In his current video, it's about none other than our RSS315 Subwoofer Kit, and the full 30 minutes, you shouldn't miss it.
Technical Specifications:
Frequency range: 20-300Hz
Fc: 35 Hz
SPL: actively recommended
B/H/T: 430x430x430mm
Gesamtimpedanz: 8 Ohm ((Nom.)
Funktionsprinzip: closed
