DSP

miniDSP 2x4HD Boxed

The miniDSP 2x4 in a box is a flexible pocket size DSP processor with 2 x analog IN, 4 x analog OUT. Combined with a plug-in software for programming, one can configure the on board Audio processing filters real time from a PC or Mac environment. Once the board configured, the device operates standalone and doesn't require a computer anymore. For more information on potential applications, please check the application section of our website. Features ADSP21489 400MHz Sharc DSP floating point engine XMOS Xcore200 for USB control and bidirectional audio streaming 24 bit ADC/DAC resolution Unbalanced inputs switchable with a jumper between 4Vrms and 2Vrms Toslink digital input Unbalanced outputs: Max 2Vrms USB Audio Class 2 Bidirectional streaming with ASIO drivers, driverless under MAC OSx 4 preset configuration, recallable via IR, Software Plug&Play USB driver and real time Software configuration using miniDSP plug-ins Device does not required a PC once configured External single 12V supply

€259.00

miniDSP Flex (RCA)

The miniDSP Flex is the 3rd generation of our popular line of compact 2-in, 4-out audio processors. It retains the powerful floating point processor but rethinks the I/O architecture so we can provide our customers with different input-output versions in this compact chassis. The initial versions are single-ended analog I/O (RCA), balanced analog I/O (TRS) and digital out with superb audiophile specification for your enjoyment. All versions include a set of digital inputs: USB audio, S/PDIF (RCA/optical) and Bluetooth (LDAC/aptX). An OLED front panel display and volume control/encoder knob provides easy control. As always, the Flex series is jam-packed with miniDSP’s tried and proven audio processing functionality: flexible parametric EQ, IIR & FIR filters, crossovers, advanced biquad programming and delay on each output channel. Last but not least, all platforms are easily software-upgradable with Dirac Live®, the world’s premiere room correction system for full range (20~20kHz) tuning. The miniDSP Flex will find a myriad uses in applications ranging from a compact digital stereo preamp through subwoofer integration and optimization to active speakers, home theater and recording studios. You just need to let your creativity do the rest! Hardware Features Processor: 32-bit floating-point 400MHz Analog Devices SHARC DSP Multi-Core USB Audio processor (XMOS) Bluetooth streaming: LDAC™/aptX™ HD/aptX™/AAC/SBC Optional upgrade to Dirac Live® 3.x Digital Room Correction, Full Range Room Correction (20~20kHz) Audiophile performance (SNR@120dB(A), THD+N @ -110dB (0.0003%) Inputs: Stereo digital (USB Audio/SPDIF/Optical/Bluetooth), stereo analog (Unbalanced RCA) Flexible Output versions: Unbalanced (RCA), Balanced (TRS), Digital (Future) USB audio recording feature (4xCH processed output via USB audio to record inputs, e.g. Vinyl) White/Black OLED front panel controller with IR control What's in the box? Digital Audio Processor — Flex based on the I/O configuration selected. No Dirac Live license for default configuration IR remote v2 12V univeral power supply (UK/EU/US/AU plugs)

€649.95

miniDSP Flex (TRS) Symmetrisch

€750.00

miniDSP Flex digital (SPIDF/TOS)

€649.95

miniDSP Flex Eight 2x8

TheFlex Eightis the latest member of the miniDSP Flex family of advanced audio processors. We’ve taken advantage of our flexible hardware architecture to cram a full eight channels of DSP and a world-class analog output stage into the compact enclosure.With multiple digital inputs and eight unbalanced analog output channels, the miniDSP Flex Eightcan implement active speakers up to stereo four-way. Flexible 2x8 signal routing supports many other configurations such as two-way, three-way and multiple subwoofers. As always, a full suite of miniDSP’s tried and proven audio processing functionality is included: parametric EQ, IIR & FIR filters, crossovers, advanced biquad programming and delay on each output channel.TheFlex Eighthas USB audio, S/PDIF (RCA and optical) and Bluetooth (LDAC/aptX) stereo digital inputs. An OLED front panel display and volume control/encoder knob provides easy control. Last but not least, it is easily software-upgradable with Stereo Dirac Live® for full range correction (20~20kHz), the world’s premiere room correction system. The miniDSPFlex Eightis the perfect solution for a modern compact integrated active speaker/subwoofer system. You just need to let your creativity do the rest!STOCK STATUS (18/10/2022):The Flex Eight is unfortunately out of stock at this time. We're expecting a new shipment by end of November. All orders will be backlogged and shipping in chronological order. Thanks for your patience! Hardware FeaturesProcessor: 32-bit floating-point 400MHz Analog Devices SHARC DSP Multi-Core USB Audio processor (XMOS) Bluetooth streaming: LDAC™/aptX™ HD/aptX™/AAC/SBC Optional upgrade to Dirac Live® 3.x Digital Room Correction, Stereo Full Range Room Correction (20~20kHz) Audiophile performance with very low noise floor and distortion (SNR @128dB(A), THD+N @ -111dB (0.0003%) Inputs: Stereo digital (USB Audio/SPDIF/Optical/Bluetooth) Outputs: Unbalanced (RCA) White/Black OLED front panel controller with IR control Control and configuration by miniDSP Device Console (DC) Weißes/schwarzes OLED-Bedienfeld auf der Vorderseite mit IR-Steuerung Steuerung und Konfiguration über miniDSP-Gerätekonsole (DC)

€799.00

Only 1 available

miniDSP C-DSP 8x12 v2

8-IN 12-OUT ADVANCED IN-CAR AUDIO PROCESSOR The C-DSP 8x12 is miniDSP’s next-generation processor for high-end mobile/car audio. The powerful 400 MHz SHARC floating-point processor provides pristine high-resolution audio at internal sample rates up to 192 kHz. With a wealth of inputs and outputs in a compact, rugged enclosure, the C-DSP 8x12 is suitable for installations from simple stereo, through surround systems with subwoofer integration, up to advanced multichannel active systems. New to this upgraded version are the onboard 32bit AKM converters that provide low noise and improved dynamic range to perfect your miniDSP experience. The driverless USB interface is used to configure miniDSP’s powerful but easy-to-use audio processing: parametric EQ on all inputs and outputs, compressors and adjustable time delay on all outputs, crossovers up to 48 dB/octave, and an advanced matrix mixer. Four complete processing configurations are stored in flash memory for instant recall with a wired or infrared remote. Hardware features dedicated to the vehicle environment include an on-board isolated power supply, remote trigger input/output, a wired remote for dash or console mounting, and a microSD card slot for offline configuration and firmware updates. Features 400MHz 32bit Sharc Floating point processor, Up to 192kHz processing 32bit DAC/ADC chipsets THD+N 0.0007%, 115dB SNR Digital and analog inputs (Low/High levels), 12 analog outputs Flexible DSP processing blocks, Rear Fill processing (L-R, L+R..) thanks to internal matrix Fully differential balanced inputs Optional Dirac live upgrade Windows/Mac compatible GUI Remote control or preset/master & sub volume control What's in the box? 1 x C-DSP 8x12 DSP processor 1 x 1m USB cable 1 x Control GUI plugin provided automatically under UserDownloads section on purchase 1 x 5m remote cable + OLED Remote control module 1 x C-DSP 8x12 plugin license

€699.95

PWR-ICE 125

Introducing the PWR-ICE125, a DSP powered plate amplifier module for active 2 way loudspeakers or mono subwoofers. Result of the collaborative effort of two innovative technology companies, the PWR-ICEs series key features are: On the processing side is miniDSP's innovative software & firmware allowing a Plug & Play real time control of the onboard DSP over Ethernet/Wifi networks. Using our Zero Conf technology, multiple modules are automatically discovered and controlled from a single User interface in real time. The onboard Digital Signal Processors (DSP) provide real time all the processing a speaker designers will expect to excel at his crossover design task. These include FIR and IIR filters (biquad input), Parametric Equalizers (PEQ), level, crossovers, comp/limiter, delay and more. The Graphical User Interface (GUI) platform is supported on both Mac and Windows environment. On the power amplifier side, the ICEpower® modules are complete AC plug-to-speaker amplification audio solutions offering flexible two-channel or bridgeable speaker drive. Their compact size, audiophile audio quality and high power output make them perfect for high-performing audio products. The amplifier is rated for up to 2x125W @ 4Ω or 1 x 450W @ 4Ω. As for audio connectivity, the PWR-ICE125 is fitted with both analog balanced (XLR) & unbalanced inputs (RCA) to provide maximum compatibility. A digital input (AES-EBU) saves on the A-D conversion for maximum performance while a Digital output (AES-EBU) allows multiple plate amplifiers to be linked to each other. Features DSP Powered plate amplifier FIR + IIR filter options / Please consult manual for details. Powered by ICEpower® technology for 2x125W @ 4Ω or 1 x 450W @ 4Ω Windows & Mac IP control Analog & Digital input Multi-unit control via Ethernet What's in the box? 1 x PWR-ICE125 amplifier module 1 x CAT5 patch cable 1 x IEC power cord 4 x black wood screws for mounting 1 x Speaker wire harness to connect amplifier to speaker (60cm long) Access to UserDownloads section for free PWR-ICE IIR/FIR plugin.

€599.00

miniDSP Flex HTx

miniDSP Flex HTxThe Flex HTx is the bigger brother of the Flex HT and targets the need for a multi-channel processor with HDMI ARC/eARC capabilities and excellent analog and USB audio capabilities. In a single rack unit, we have included all possible connections we could find.The eight-channel audio input is via analog audio (RCA and TRS), eARC linear PCM via HDMI1, or USB Audio. An additional digital stereo input is supported via SPDIF and TOSLINK optical. Internally, we have provided a complete suite of flexible miniDSP routing and audio processing functions: bass management, parametric EQ, crossovers, advanced biquad programming, and delay/gain adjustments. Furthermore, the miniDSP Flex HTx can be upgraded via software with Dirac Live®, the world's leading room correction system.The Flex HTx focuses miniDSP on affordable high-performance audio and features class-leading noise and distortion values. An OLED display on the front and a volume control/encoder knob allow for easy control.The miniDSP Flex HTx is the perfect solution for a modern compact processor for home theater and multichannel sound.NOTE: Please note that the Flex HTx does not support bitstream decoding (e.g., Dolby/DTS). The audio source must be capable of outputting linear PCM (LPCM) to support multichannel sound over HDMI. Hardware FeaturesProcessor: 32-bit floating point 400MHz Analog Devices SHARC DSPMulticore USB Audio Processor (XMOS)HDMI EARC/ARC interface for multichannel sound in PCM. Note that Flex HTx does not support the bitstream format (Dolby/DTS encoded).Optional upgrade to Dirac Live® 3.x Digital Room Correction, Multichannel (8-channel) Full Bandwidth Room Correction (20~20kHz)Audiophile performance with very low noise floor and distortion (SNR @127dB(A), THD+N @ -120dB (0.0001%)Inputs: Stereo digital (SPDIF/Optical), Multichannel USB Audio Streaming (up to 7.1)Outputs: 8 audio channels duplicated on unbalanced (RCA)White/black OLED controller on the front with IR controlControl and configuration via miniDSP Device Console (DC)Rack Mounting with Removable Rack EARS

€1,299.95

miniDSP Flex HT 8 Kanal DSP

miniDSP Flex HT 8 Channel DSPminiDSP Flex HT, 400 MHz Sharc DSP audio processor, 8-channel DAC, toolbox for subwoofer or multi-way speaker tuning, USB/HDMI ARC/EARC, optional WISA, optional Multichannel Dirac Live license for room correction.The Flex HT is miniDSP's response to our customers' requests for a pocket-sized multi-channel processor with HDMI ARC/eARC capabilities. Our team managed to pack full eight-channel DSP performance and a wide range of inputs and outputs into the incredibly compact enclosure.The eight-channel audio input is via eARC linear PCM over HDMI or USB audio. Additional stereo input is supported via SPDIF and TOSLINK optical. Internally, we have provided a full suite of miniDSP's flexible routing and audio processing functions: bass management, parametric EQ, crossovers, advanced biquad programming, and delay/gain adjustments. Additionally, the miniDSP Flex HT is software upgradeable with Dirac Live® full frequency, the world's leading room correction system.The eight-channel analog RCA outputs feature class-leading noise and distortion values. And last but not least, the Flex HT is the first product from miniDSP to offer WiSA capability (“Wireless Speaker and Audio Association”) as an optional feature (in the future). WiSA was specifically developed for low-latency multi-channel audio – a perfect complement to the Flex HT. The WiSA transmitter enables the lossless transmission of all eight output channels to WiSA-compatible speakers and subwoofers. Please note that the WiSA function will be a hardware option in future deliveries (expected Q1 2024) and is not included at this time.The miniDSP Flex HT is the perfect solution for a modern compact processor for home theater and multi-channel sound. The rest is up to your creativity!REMINDER: Please note that the Flex HT does not support bitstream decoding (e.g., Dolby/DTS). The audio source must be capable of outputting linear PCM (LPCM) for multichannel support over HDMI.

€799.95

New

miniDSP ADept USB Connector

Audiophiler Analog-Digital-Wandler (A/D) Flexibler Phono-Vorverstärker mit digitaler Signalverarbeitung (DSP)SPDIF & TOSLINK für die computerlose Digitalisierung123 dB SNR / -117 dB THD+N maximale LeistungThe miniDSP ADept is a compact high-resolution A/D (analog-to-digital) convertor that accepts single-ended (RCA) or balanced (on XLR) audio signals. The digital output is available on SPDIF coaxial and TOSLINK optical connectors, and can also be recorded to a computer or mobile device via the USB-C connector. Adept combines low latency, high sample rate and extremely low noise floor performance to provide optimal digitization of your favorite analog audio content.The miniDSP ADept is also a phono preamp (with a turntable connected to the RCA inputs) with accurate phono equalization for moving magnet or moving coil cartridges. In addition to the standard RIAA phono equalization curves, we've used the power of DSP to provide additional curves that will be of interest to the keen collector of older vinyl. A range of input gain, resistance and capacitance values are provided to optimize for any cartridge and can easily be saved and recalled in your favorite preset.miniDSP once again innovates with audiophile performance in a package that doesn’t break the bank. FeaturesAudiophile Analog to Digital (A/D) converterFlexible Phono preamp powered by Digital Signal Processing (DSP)SPDIF&TOSLINK for computerles digitization123dB SNR / -117dB THD+N max performanceApplicationsConverting your analog audio sources to Digital (SPDIF/TOSLINK/USB)Audio measurements Adding a high quality ADC to your existing systemComputerless analog conversion for an all digital audio system. This device does NOT require a PC/Mac to convert your source to SPDIF/TOSLINK output. Digitizing Vinyl contentWhat's in the box?1 x ADept A/D converter1 x 1m long USB audio cable1 x Toslink audio cable1 x IR remote Technical Specifications Description USB & DSP Audio ProcessorXMOS Multicore processor, USB Asynchronous, UAC2 interface, Firmware upgradable ADC resolution/Sample rateESS ES9842 Pro - 32 bit/44.1~192kHz USB Audio supportUAC2 Audio - Custom ASIO driver (Windows) / Driverless on (Mac/Linux/Android/IoS) Digital Audio 1 x USB audio (PCM) on USB type C Output Connectivity1 x SPDIF on RCA connector, 1 x OPTICAL on Toslink connector Supported sample rates: 44.1 ~ 192 kHz Input/Output configuration2 x channel analog in (Unbalanced RCA or Balanced XLR), 2 x channel digital out Filtering Technology / PresetsIIR / Up to 4 presets Dimensions150x180x41 mm AccessoriesIR Remote for control of source/volume/preset/standby Power SupplyIncluded external switching PSU 12V/1.6A (US/UK/EU/AU plugs) Power Consumption6 W (idle) / 0.9 W (standby) Audio Specifications Input SourceMoving Coil (MC)/RCAMoving Magnet(MM)/RCALine-in/RCALine-in/XLRSelectable Phono Equalization mode (IIR+FIR)RIAA, IEC No.98 (500R-13.7) N/AN/ADecca 33.3, London M33 (500C-12)Columbia LP M33 (500C-16)Phono EQ Accuracy Within ± 0.1 dB (20 Hz – 20 kHz) (RIAA, Decca and Columbia)Optional High Pass Filter At 20 Hz with 24 dB/octave(Subsonic filter)Maximum analog input (before digital gain & RIAA EQ if applicable, at Low, Medium, High Gain)81mV, 29mV, 12mV220mV, 110mV, 68mVN/A, 2.2 V, 1.1 VN/A, 4.4 V, 2.2 VMaximum recommended cartridge output @1kHz, 5cm/sec (Low, Medium, High Gain)4.2mV, 1.5mV, 0.6mV13mV, 6.5mV, 4mVN/AN/ASelectable Input Impedance 50 Ω, 100 Ω, 1 kΩ33 kΩ, 50 kΩ, 100 kΩ33 kΩ, 50 kΩ, 100 kΩFixed at 200 kΩ(Low, Medium, High)Selectable Input Capacitance 1 nF, 3 nF, 5 nF50 pF, 100 pF, 500 pF50 pF, 100 pF, 500 pFFixed at 100 pF(Low, Medium, High)Frequency Response20 Hz – 20 kHz ± 0.2 dB20 Hz – 20 kHz ± 0.1 dB20 Hz – 20 kHz ± 0.05 dBSNR vs Low(L), Medium(M), High(H) gain settingWith RIAA EQWith RIAA EQ122 dB(A) at med gain123 dB(A) at med gain84 dB(A) ref @ 2mV (L)95 dB(A) ref @ 10mV (L)120 dB(A) at high gain122 dB(A) at high gain79 dB(A) ref @ 1mV (M)90 dB(A) ref @ 5 mV (M) 73 dB(A) ref @ 0.5mV (H)87 dB(A) ref @ 2.5 mV (H) THD+N vs Low(L), Medium(M), High(H) gain settingWith RIAA EQWith RIAA EQ-116 dB (0.00017 %) at med gain-117 dB (0.00015 %) at med gain-77 dB (0.014 %) ref @(L)-89 dB (0.0035 %)ref @(L)-115 dB (0.0002 %) at high gain-116 dB (0.00017 %) at high gain-71 dB (0.028 %) ref @(M)-83 dB (0.007 %) ref @(M) -65 dB (0.056 %) ref @(H)-80 dB (0.01 %) ref @ (H) Crosstalk-85 dB-100 dB-132 dB-138 dB

€399.95

Only 1 available

miniDSP Flex (DL)

The miniDSPFlex is the 3rd generation of our popular line of compact 2-in, 4-out audio processors. It retains the powerful floating point processor but rethinks the I/O architecture so we can provide our customers with different input-output versions in this compact chassis. The initial versions are single-ended analog I/O (RCA), balanced analog I/O (TRS) and digital out with superb audiophile specification for your enjoyment.All versions include a set of digital inputs: USB audio, S/PDIF (RCA/optical) and Bluetooth (LDAC/aptX). An OLED front panel display and volume control/encoder knob provides easy control. As always, the Flex series is jam-packed with miniDSP’s tried and proven audio processing functionality: flexible parametric EQ, IIR & FIR filters, crossovers, advanced biquad programming and delay on each output channel. Last but not least, all platforms are easily software-upgradable with Dirac Live®, the world’s premiere room correction system for full range (20~20kHz) tuning.The miniDSPFlexwill find a myriad uses in applications ranging from a compact digital stereo preamp through subwoofer integration and optimization to active speakers, home theater and recording studios. You just need to let your creativity do the rest!Hardware Features Processor: 32-bit floating-point 400MHz Analog Devices SHARC DSPMulti-Core USB Audio processor (XMOS)Bluetooth streaming: LDAC™/aptX™ HD/aptX™/AAC/SBCOptional upgrade to Dirac Live® 3.x Digital Room Correction, Full Range Room Correction (20~20kHz)Audiophile performance (SNR@120dB(A), THD+N @ -110dB (0.0003%)Inputs: Stereo digital (USB Audio/SPDIF/Optical/Bluetooth), stereo analog (Unbalanced RCA)Flexible Output versions: Unbalanced (RCA), Balanced (TRS), Digital (Future) USB audio recording feature (4xCH processed output via USB audio to record inputs, e.g. Vinyl)White/Black OLED front panel controller with IR controlWhat's in the box? Digital Audio Processor — Flex based on the I/O configuration selected. No Dirac Live license for default configuration IR remote v2 12V univeral power supply (UK/EU/US/AU plugs) Bluetooth-Streaming: LDAC™/aptX™ HD/aptX™/AAC/SBC Optionales Upgrade auf Dirac Live® 3.x Digitale Raumkorrektur, Full Range Room Correction (20~20kHz) Audiophile Leistung (SNR@120dB(A), THD+N @ -110dB (0.0003%) Eingänge: Stereo-Digital (USB Audio/SPDIF/Optical/Bluetooth), Stereo-Analog (unsymmetrischer RCA) Ausgang: digital,4 x Output channels(Post DSP)on USB Audio andSPDIF& TOSLINK (duplicated) USB-Audioaufnahmefunktion (4xCH verarbeiteter Ausgang über USB-Audio zu Aufnahmeeingängen, z. B. Vinyl) Weißes/schwarzes OLED-Bedienfeld mit IR-Steuerung Was ist im Lieferumfang enthalten? Digitaler Audioprozessor - Flex basierend auf der gewählten I/O-Konfiguration. Keine Dirac Live-Lizenz für die Standardkonfiguration IR-Fernbedienung v2 12V-Universal-Netzteil (UK/EU/US/AU-Stecker)

€948.95
